Replacement for Stabilus Lift-O-Mat 094838 0350N
Replacement gas spring for the Stabilus Lift-O-Mat 094838 0350N. The eye has a thickness of 10mm and a hole diameter of 8.1mm. Brand: Stabilus Industry Line.
The thickness of the eye of this replacement is 10mm instead of 5mm. This gas spring is also known as CA094838.
The diameter of the cylinder of this gas spring is 19 mm. The diameter of the rod is 8 millimeter. The rod (the chrome part) is 180 mm long. The total length of this replacement is 443 millimeter. Keep in mind that this is the length between the centers of the mounting parts. Without the mounting parts this gas spring is 405 mm long (thread to thread). This replacement gas spring (094838) has a force of 350 Newton (N). This is not an original gas spring from Stabilus Lift-O-Mat, but a so called replacement gas spring. HAHN Gasfedern, a Stabilus subsidiary, is responsible for the production of this replacement gas spring. The gas spring has the brand Stabilus Industry Line. The gas spring can be used without problems as a replacement, because the dimensions and force close to equal.
