Replacement for Ferron 552 50-800N
Replacement gas spring for the Ferron 552 50-800 Newton. The eye has a thickness of 10mm and a hole diameter of 8.1mm. Brand: Stabilus Industry Line.
The thickness of the eye of this replacement is 10mm instead of 5mm.
The bore of the house of this replacement gas spring is 19 mm. The diameter of the rod is 8 millimeter. The stroke (the retracting part) has a length of 300 mm. The total length of this replacement gas spring is 683 mm. Note: this is the total length between the rotation points of the two mounting parts. The distance from thread to thread (without mounting parts) is 645 mm. This gas spring (552) has a force of 50-800 Newton. This is not an original gas spring from Ferron, but a so called replacement gas spring. This a gas spring with the brand Stabilus Industry Line. Nevertheless, the force and dimensions almost entirely equal.
