Replacement for Stabilus Lift-O-Mat 084840 1000N

$30.94




Replacement gas spring for the Stabilus Lift-O-Mat 084840 1000N. The eye has a thickness of 10mm and a hole diameter of 8.1mm. Brand: Stabilus Industry Line.

Please note:
  • The thickness of the eye of this replacement is 10mm instead of 5mm.
  • The diameter of the tube of this replacement gas spring is 23mm instead of 22mm.
  • This gas spring is also known as CA084840.
    Stabilus Lift-O-Mat 084840
    AR19


    The diameter of the black cylinder of this gas spring is 23 millimeter. The cross section of the rod is 10 mm. The stroke of the gas spring is 100 millimeter. The total length of this replacement gas spring is 283 mm. This is the distance between the centers of the mounting parts. The length from thread to thread (exlcuding the mounting parts) is 245 millimeter. This gas spring (084840) has a force of 1000 Newton. This is not an original gas spring from Stabilus Lift-O-Mat, but a so called replacement gas spring. This gas spring was produced by Stabilus subsidiary Hahn with the brand Stabilus Industry Line. The force (1000 N) and dimensions are almost entirely identical to the original.
