Replacement for Stabilus Lift-O-Mat 084972 1000N

$41.57




Replacement gas spring for the Stabilus Lift-O-Mat 084972 1000N. The eye has a thickness of 10mm and a hole diameter of 8.1mm. Brand: HAHN, a Stabilus company.

Please note:
  • The thickness of the eye of this replacement is 10mm instead of 5mm.
  • The diameter of the tube of this replacement gas spring is 23mm instead of 22mm.


    • View this gas spring in our configurator.
    This gas spring is also known as CA084972.
    Stabilus Lift-O-Mat 084972
    AR19


    The diameter of the cylinder of this gas spring is 23 mm. The diameter of the rod is 10 millimeter. The stroke of the gas spring is 250 millimeter. In total, the length is 583 millimeter. This is the total distance between the centers of the two mounting parts. The distance from thread to thread (without mounting parts) is 545 mm. This replacement gas spring (084972) has a force of 1000 Newton (N). Attention: this is not an official Stabilus Lift-O-Mat gas spring, but a replacement gas spring. This gas spring was produced by Stabilus subsidiary HAHN. The gas spring can be used without problems as a replacement, because the dimensions and force nearly equal.
    Category:
    Replacement for Stabilus Lift-O-Mat 084972 1000N
