Replacement for Stobo 4100314- 1000N

$90.40




Replacement gas spring for the Stobo 4100314- 1000 Newton. The eye has a thickness of 10mm and a hole diameter of 10.1mm. Brand: HAHN, a Stabilus company.

Please note:
  • Mounting part tube: The thickness of the eye of this replacement is 10mm instead of 12mm.
  • Mounting part rod : The thickness of the eye of this replacement is 10mm instead of 18mm.


    • View this gas spring in our configurator.

    Stobo 4100314-
    AU27


    This gas spring has a cylinder diameter of 28 mm. The cross section of the rod is 14 mm. The stroke is 500 millimeter long. The total length of this replacement is exactly 1102 mm. Attention: this is the length between the centers of the mounting parts. Without the mounting parts this gas spring is 1048 mm long (thread to thread). This replacement gas spring (4100314-) has a force of 1000 Newton (N). This is not an original gas spring from Stobo, but a so called replacement gas spring. This gas spring was produced by Stabilus subsidiary HAHN. Nevertheless, the dimensions and force are nearly equal.
    Category:
    Replacement for Stobo 4100314- 1000N
