Replacement for Stabilus Lift-O-Mat 095583 0350N

$58.86




Replacement gas spring for the Stabilus Lift-O-Mat 095583 0350N. This fits a (possibly already present) ball with a diameter of 10mm. A corresponding ball is included. Brand: HAHN, a Stabilus company.

Please note:
The diameter of the tube of this replacement gas spring is 23mm instead of 22mm.

View this gas spring in our configurator.
This gas spring is also known as CA095583.
Stabilus Lift-O-Mat 095583
WG20
elbow ball removal

The diameter of the black cylinder of this gas spring is 23 millimeter. The diameter of the rod is 10 millimeter. The stroke of the gas spring is 400 millimeter. In total, the length is 885 millimeter. This is the distance between the centers of the mounting parts. Without the mounting parts this gas spring is 845 mm long (thread to thread). The force of this replacement is 350 Newton. This is not an original gas spring produced by Stabilus Lift-O-Mat, but it can replace a Stabilus Lift-O-Mat gas spring. HAHN Gasfedern, a Stabilus subsidiary, is responsible for the production of this replacement gas spring. The gas spring has the brand HAHN. Nevertheless, this gas spring can be used as replacement gas spring, because the dimensions and forces are nearly equal.
